€ 39,95

+ 79 punten

Verwachte beschikbaarheidsdatum onbekend

Eenvoudig bestellen

Veilig betalen

Gratis thuislevering vanaf € 30 (via bpost)

Gratis levering in je Standaard Boekhandel

Omschrijving

The latest iteration of KiCad, the world's best free-to-use Printed Circuit Board tool, is packed with features usually found only in expensive commercial CAD tools. This modern, cross-platform application suite built around schematic and design editors, with auxiliary applications is a stable and mature PCB tool. KiCad 6 is a perfect fit for electronic engineers and hobbyists.

Here are the most significant improvements and features in KiCad 6, both over and under the hood:

Modern user interface, completely redesigned from earlier versions
Improved and customizable electrical and design rule checkers
Theme editor allowing you to customize KiCad on your screen
Ability to import projects from Eagle, CADSTART, and more
Enhanced bus handling
Full control over the presentation of information by the layout editor
Filters define selectable elements
Enhanced interactive router helps you draw single tracks and differential pairs with precision
New or enhanced tools to draw tracks, measure distances, tune track lengths, etc.
Enhanced tool for creating filled zones
Easy data exchange with other CAD applications
Realistic ray-tracing capable 3D viewer
Huge community of contributors that make KiCad better every day
Rich repositories of symbol, footprint, and 3D shape libraries

This book will teach you to use KiCad through a practical approach. It will help you become productive quickly and start designing your own boards. Example projects (e.g., a simple breadboard power supply and a PCBA 4×8×8 LED matrix array) illustrate the basic features of KiCad, even if you have no prior knowledge of PCB design. The author describes the entire workflow from schematic entry to the intricacies of finalizing the files for PCB production and offers sound guidance on the process. Further full-fledged projects, of incremental difficulty, will be presented in a second book, together with a variety of advanced recipes.
